QuickJack is constantly improving and evolving to fit your automotive needs in the garage or on the track. 5000TL is the highly-anticipated sequel to the most popular automotive tool to ever hit the home garage or auto repair shop. With the ability to lift an extra 3-inches, 5000TL portable car lift provides more room to tackle every repair and maintenance task on vehicles weighing up to 5,000-lbs.

Through superior engineering and design, we've been able to produce an extra 3-inches of lifting height without sacrificing the overall dimensions that has made QuickJack a must-have in your garage. 5000TL still has an impressive 3" lowered height, 70" overall length, and 11" overall width.

What's the difference between the NEW TL Models vs. SLX Models?

The biggest difference between the 5000TL and BL-5000SLX is the lifting height, which has increased 3 inches. This provides ample room to perform all the common vehicle maintenance tasks and allows you the capability to perform even the most complicated repairs.

Overall dimensions have remained the same, so you'll continue to benefit from what made QuickJack so popular in the automotive community and that is it's super-low 3" lowered height. The minimum lifting point spread did change from 31.5" to 37", but this will not make a difference to the vast majority of 5000TL users.

I already own a QuickJack, can I purchase the frames individually?

Yes! You can purchase the left frame and right frame individually without a power unit. Just make sure to follow the bleeding procedures on the new frames before operating. Keep in mind that purchasing frames individually will only include the frames themselves and no support equipment.

Click here to order TL Frames

If I purchase this TL model today, when will it arrive?

We have a limited quantity of the 5000TL that we've made available to TL members only at this time. These units are in stock and available to ship within 1-2 business days of purchase.

What is the warranty period on the TL models?

All TL models include a 1-year warranty on equipment structure and operating components comes standard. You can also purchase an optional 2-year extended warranty. Learn more about QuickJack warranty.

Features

Tech specs

Lifting capacity

5,000 lbs. (2,268 kg)

Lowered height

A - With 2" block: 3.5" (89 mm)

Lifting height

B - With 2" block: 21" (521 mm)C - With 3" block: 22" (546 mm)D - Max. height: 24" (616 mm)E - With adapters: 24" (597 mm)F - With adapters + pin: 26.75" (673 mm)Compare All Specifications

Lift point spread

G - Maximum: 60" (1,524 mm)H - Minimum: 37" (940 mm)

Frame dimensions (ea.)

I - Width: 11" (278 mm)J - Length: 70" (1,778 mm)Weight: 78 lbs. (35 kg)

Other specs

Time to full rise: 30 secondsPower unit weight: 15 lbs. (7 kg)Shipping dimensions (ea. frame):
73.5" (L) x 15.25" (W) x 5" (H)
(1,869 mm x 385 mm x 129 mm)Shipping weight: 240 lbs. (109 kg)
